产品参数
+
型号通道数电压电流功率精度分辨率通讯接口尺寸
N3608-080-060180V60A800W电压≤0.05%+0.05%F.S. / 电流≤0.1%+0.1%F.S.1mV/1mARS232/LAN2U
N3612-080-060180V60A1,200W电压≤0.05%+0.05%F.S. / 电流≤0.1%+0.1%F.S.1mV/1mARS232/LAN2U
N3612-240-0301240V30A1,200W电压≤0.05%+0.05%F.S. / 电流≤0.1%+0.1%F.S.10mV/1mARS232/LAN2U
N3618-080-120180V120A1,800W电压≤0.05%+0.05%F.S. / 电流≤0.1%+0.1%F.S.1mV/10mARS232/LAN2U
N3618-016-250116V250A1,800W电压≤0.05%+0.05%F.S. / 电流≤0.1%+0.1%F.S.1mV/10mARS232/LAN2U
N3618-240-0601240V60A1,800W电压≤0.05%+0.05%F.S. / 电流≤0.1%+0.1%F.S.10mV/1mARS232/LAN2U
N3618-360-0351360V35A1,800W电压≤0.05%+0.05%F.S./电流≤0.1%+0.1%F.S.10mV/1mARS232/LAN2U
N3618-600-0051600V5A1,800W电压≤0.05%+0.05%F.S. / 电流≤0.1%+0.1%F.S.10mV/1mARS232/LAN2U
N3618-600-0201600V20A1,800W电压≤0.05%+0.05%F.S. / 电流≤0.1%+0.1%F.S.10mV/1mARS232/LAN2U
N3618-800-0151800V15A1,800W电压≤0.05%+0.05%F.S. / 电流≤0.1%+0.1%F.S.10mV/1mARS232/LAN2U
N3618-1000-01011000V10A1,800W电压≤0.05%+0.05%F.S. / 电流≤0.1%+0.1%F.S.100mV/1mARS232/LAN2U
N3618-1200-00811200V8A1,800W电压≤0.05%+0.05%F.S. / 电流≤0.1%+0.1%F.S.100mV/1mARS232/LAN2U
N3630-016-500116V500A3,000W电压≤0.05%+0.05%F.S. / 电流≤0.1%+0.1%F.S.1mV/10mARS232/LAN2U
N3630-080-120180V120A3,000W电压≤0.05%+0.05%F.S. / 电流≤0.1%+0.1%F.S.1mV/10mARS232/LAN2U
N3630-240-0601240V60A3,000W电压≤0.05%+0.05%F.S. / 电流≤0.1%+0.1%F.S.10mV/1mARS232/LAN2U
N3630-360-0351360V35A3,000W电压≤0.05%+0.05%F.S. /电流≤0.1%+0.1%F.S.10mV/1mARS232/LAN2U
N3630-600-0201600V20A3,000W电压≤0.05%+0.05%F.S. / 电流≤0.1%+0.1%F.S.10mV/1mARS232/LAN2U
N3630-800-0151800V15A3,000W电压≤0.05%+0.05%F.S. / 电流≤0.1%+0.1%F.S.10mV/1mARS232/LAN2U
N3630-1000-01011000V10A3,000W电压≤0.05%+0.05%F.S. / 电流≤0.1%+0.1%F.S.100mV/1mARS232/LAN2U
N3630-1200-00811200V8A3,000W电压≤0.05%+0.05%F.S. / 电流≤0.1%+0.1%F.S.100mV/1mARS232/LAN2U
N3660-016-1000116V1000A6,000W电压≤0.05%+0.05%F.S. / 电流≤0.1%+0.1%F.S.1mV/100mARS232/LAN4U
N3660-080-240180V240A6,000W电压≤0.05%+0.05%F.S. / 电流≤0.1%+0.1%F.S.1mV/10mARS232/LAN4U
N3660-240-1201240V120A6,000W电压≤0.05%+0.05%F.S. / 电流≤0.1%+0.1%F.S.10mV/10mARS232/LAN4U
N3660-360-0701360V70A6,000W电压≤0.05%+0.05%F.S. / 电流≤0.1%+0.1%F.S.10mV/1mARS232/LAN4U
N3660-600-0401600V40A6,000W电压≤0.05%+0.05%F.S. / 电流≤0.1%+0.1%F.S.10mV/1mARS232/LAN4U
N3660-800-0301800V30A6,000W电压≤0.05%+0.05%F.S. / 电流≤0.1%+0.1%F.S.10mV/1mARS232/LAN4U
N3660-1000-02011000V20A6,000W电压≤0.05%+0.05%F.S. / 电流≤0.1%+0.1%F.S.100mV/1mARS232/LAN4U
N3660-1200-01611200V16A6,000W电压≤0.05%+0.05%F.S. / 电流≤0.1%+0.1%F.S.100mV/1mARS232/LAN4U
N3690-016-1500116V1500A9,000W电压≤0.05%+0.05%F.S. / 电流≤0.1%+0.1%F.S.1mV/100mARS232/LAN6U
N3690-080-360180V360A9,000W电压≤0.05%+0.05%F.S. / 电流≤0.1%+0.1%F.S.1mV/10mARS232/LAN6U
N3690-240-1801240V180A9,000W电压≤0.05%+0.05%F.S. / 电流≤0.1%+0.1%F.S.10mV/10mARS232/LAN6U
N3690-360-1051360V105A9,000W电压≤0.05%+0.05%F.S. / 电流≤0.1%+0.1%F.S.10mV/10mARS232/LAN6U
N3690-600-0601600V60A9,000W电压≤0.05%+0.05%F.S. / 电流≤0.1%+0.1%F.S.10mV/1mARS232/LAN6U
N3690-800-0451800V45A9,000W电压≤0.05%+0.05%F.S. / 电流≤0.1%+0.1%F.S.10mV/1mARS232/LAN6U
N3690-1000-03011000V30A9,000W电压≤0.05%+0.05%F.S. / 电流≤0.1%+0.1%F.S.100mV/1mARS232/LAN6U
N3690-1200-02411200V24A9,000W电压≤0.05%+0.05%F.S. / 电流≤0.1%+0.1%F.S.100mV/1mARS232/LAN6U
